2.2.5 Auto Heading Adjust
The compass has been calibrated during manufacture. This calibration will be
satisfactory for almost all installations. If you have a steel vessel, or some
other factor which causes the compass to perform poorly, the calibration
procedure will adjust compass characteristics to compensate.
The calibration should only be done if the compass is known to be inaccurate.
If the KAP-866 display as constant offset (e.g. The compass reads 3 degrees
high on all bearings), simply rotate the Fluxgate Sensor case to align bearings
with the ships compass. It is not necessary to re-calibrate the compass as desc-
ribed below.
If the KAP-866 has inconsistent variation on different headings, the following
calibration procedure can be carried out. This procedure should only be done
in calm waters with adequate sea room.
In the menu select"AUTO HEADING ADJUST"and press knob The following
window appears:
Press the knob to start auto heading adjustment "Auto heading adjusting"
message will appear on the lower part of the display and heading update per
second to show the status of adjustment.
SELECT REMOTE UNIT
SELECT RUDDER FEEDBACK UNIT
SELECT MAGNETIC SENSOR UNIT
TRIM SETTING
INSTALLATION MENU
AUTO HEADING ADJUST
MANUAL HEADING SETTING
HEADING ALIGNMENT SETTING
LANGUAGE SETTING
AUTO HEADING ADJUST
Cancel [ES C] ok [EN T]
Auto heading adjusting !
Pleases keep constant speed less
than 2 minutes for each turn
40 50 60 70 80 E 100 110 120
080
Weather
Rudder
Counter
Mode
060
Set Course
Auto heading adjusting...
15
