11.5 Zoom Mode
11.5.1 Extended Zoom Mode
In extended zoom mode the zoom position of
the reflector is reduced to one level below
the focal length of the camera lens. The
resulting expanded and broader light covera-
ge provides additional dispersed light (reflec-
tions) inside rooms so that a softer flash illu-
mination is possible.
Example:
The focal length of the camera lens is 50 mm.
The extended zoom mode sets a 35 mm
reflector position on the flash unit. However,
50 mm continues to be shown on the display.
Setting procedure
• Press the ቨ button as often as it takes
for the selection menu to appear.
• Press the sensor button on the
touch display.
• Press the sensor buttons on the
touch display and select .
• Press the button as often as it
takes for the selection menu to appear.
• Press the sensor button on the
touch display.
The setting is adopted immediately.
After activation of extended zoom mode,
"EXT" appears in the INFO menu.
D
OPTION
ZOOM MODE
ZOOM MODE
EXTENDED
Depending on the system, the extended
zoom mode is supported for lens focal
lengths of 28 mm or more (35-mm format).
The camera must be equipped with a CPU
lens and be able to transfer data on the lens
focal length to the flash unit.
11.5.2 SPOT zoom mode
In spot zoom mode, the zoom position of the
reflector is increased by one level compared
to the focal length of the camera lens. The
resulting reduced illumination provides
centre-weighted illumination or alternatively
shadowy edge lighting.
Example:
The focal length of the camera lens is 50 mm.
The spot zoom mode sets a 70 mm reflector
position on the flash unit. However, 50 mm
continues to be shown on the display.
Setting procedure
• Press the
ቨ button as often as it takes
for the selection menu to appear.
• Press the sensor button on the
touch display.
• Press the sensor buttons on the
touch display and select .
• Press the sensor button on the
touch display.
D
OPTION
ZOOM MODE
ZOOM MODE
194
OPTION
ZOOMMODE
O
Extended
Standard
Spot
OPTION
O
q p
ZOOM SIZE
ZOOM MODE
STANDBY
OPTION
OPTION
O
q p
ZOOM SIZE
ZOOM MODE
STANDBY
k
