Wall Bracket
Layout Rev. A
Agencement des supports
muraux, Rév. A
Esquema del soporte
de pared, Rev. A
28 5 /
16
"
(719 mm) 28 1 /
4
"
(718 mm)
1 /
4
"
(6 mm)
Overhead Cabinet Outline
Empreinte du
placard mural
Esbozo del
gabinete colgado
2"
(51 mm)
Slot
Fente
Ranura
Top Wall Bracket
Support mural supérieur
Soporte superior de pared
1 / 4 "
(6 mm)
.188 x 1.250 Slots
Trous de 6 mm
(0,250") de diam.
Agujeros de 6 mm
(0,250") de diámetro
Bottom Wall Bracket
Support mural inférieur
Soporte inferior de pared
.188 x 1.250 Slots
TM
®
GABINETE COLGADO
OVERHEAD CABINET
PLACARD MURAL
