PointScan/300 User’s Manual 9-12-01 Table PointScan I/O Modules and Accessories A-1
Table PointScan I/O Modules and Accessories A
Distributed I/O Modules
Definition
Ethernet RS-485 PT-Bus
Description
Analog Inputs
8 Analog Inputs
(4 to 20 mA)
— PointScan/201 PointScan/301
Measure analog current with 14-bit resolution
16 Analog Inputs
(4 to 20 mA)
PointScan/102 PointScan/202 PointScan/302
Measure analog current with 14-bit resolution
16 Analog Intputs
(Current Limiters)
— — PointScan/303
Provides short circuit protection for 4 to 20 mA inputs
8 Universal Analog Inputs
(TC, mA, V, mV)
PointScan/104 PointScan/204 PointScan/304
Measure TCs (J, K, E, R, T, B, C, N, S), floating 4 to 20
mA, or mV, V with 16-bit resolution
8 Analog Inputs
(±1, 2, 5 10V)
— — PointScan/305
Measure voltage inputs with 12-bit resolution
6 RTD Inputs
(100 Ohm Platinum)
— — PointScan/306
Measure 100 Ohm platinum RTDs (2, 3, or 4 wire) with
16-bit resolution
6 RTD Inputs
(10 Ohm Copper)
— — PointScan/307
Measure 10 Ohm copper RTDs (2 or 3 wire) with 16-bit
resolution
Combination I/O
8 Analog Inputs &
4 Analog Outputs
(4 to 20 mA)
PointScan/108 — —
Provides 4 to 20 mA inputs and outputs with 16-bit
resolution
4 RTD Inputs & 4 Digital Outputs
(100 Ohm Platinum,
12/24 VDC/VAC)
PointScan/109 — —
Measure 100 Ohm platinum RTDs (2, 3, or 4 wire) and
digital inputs
Analog Outputs
4 Analog Outputs
(4 to 20 mA) — PointScan/216 PointScan/316 Provides 4 to 20 mA outputs with 13-bit resolution
8 Analog Outputs
(4 to 20 mA) — PointScan/217 PointScan/317 Provides 4 to 20 mA outputs with 13-bit resolution
8 Analog Outputs
(±5V, ±10V, 0 to 5V, 0 to 10V) — — PointScan/318 Provides voltage outputs with 14-bit resolution
Digital Inputs
8 Digital Inputs
(12/24 VDC/VAC)
— PointScan/221 PointScan/321
Read digital (ON/OFF) inputs
16 Digital Inputs
(12/24 VDC/VAC)
PointScan/122 PointScan/222 PointScan/322
Read digital (ON/OFF) inputs
8 Digital Inputs
(5 VDC)
— — PointScan/323
Read digital (ON/OFF) inputs
8 Digital Inputs
(48 VDC/VAC)
— — PointScan/324
Read digital (ON/OFF) inputs
8 Digital Inputs
(120 VDC/VAC)
— — PointScan/325
Read digital (ON/OFF) inputs
8 Digital Inputs
(240 VAC)
— — PointScan/326
Read digital (ON/OFF) inputs
8 HS Counters with Encoders
(32-bit, 4 to 30V)
PointScan/127 — PointScan/327
Count rates up to 50-kHz plus quadrature encoder
Combination I/O
4 Digial Inputs & Outputs
(12/24 VDC)
— PointScan/228 —
Read digital (ON/OFF) inputs, switch digital (ON/OFF)
outputs
8 Digial Inputs & Outputs
(12/24 VDC)
PointScan/129 — —
Read digital (ON/OFF) inputs, switch digital (ON/OFF)
outputs
8 Digital Inputs & 8 Analog Inputs
(12/24 VDC/VAC, 4 to 20 mA)
PointScan/130 — —
Read digital (ON/OFF) inputs, output 4 to 20 mA with
16-bit resolution
4 Digital Inputs & 4 Analog Inputs
(12/24 VDC/VAC, 4 to 20 mA)
— PointScan/231 —
Read digital (ON/OFF) inputs, output 4 to 20 mA with
16-bit resolution
