5
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
2. ASSEMBLY
A. For RMC-KFA45T/RMC-KFA65T Models
only (Figure 6)
Tools Required
• Medium Phillips Screwdriver
1. Align the holes on the upper shell
with the 2 mounting holes on the
handle as shown in Figure 6.
2. Secure each hole with a screw.
B. For RMC-KFA120T / RMC-KFA170T / RMC-KFA210T Models only (Figure 7)
These models are furnished with wheels and handles. Wheels, handles, and the mounting
hardware are found in the shipping carton.
Tools Required
• Medium Phillips Screwdriver
• 5/16"(M5) open or Adjustable Wrench. Use US(INCH) Screws Nuts
• Long Nose Pliers
1. Slide axle through wheel support frame. Install wheels on axle.
NOTE: When installing wheels, point extended hub of wheels toward
wheel support frame (see Figure 7)
2. Place Flat washers and split pin on axle ends and bend split pins with long
nose pliers to secure.
3. Place heater on wheel support frame. Make sure air inlet end (rear) of heater is
over wheels. Align the holes on fuel tank flange with holes on wheel support frame.
4. Position the handle on top of fuel tank flange. Insert screws through handles, fuel
tank flange, and wheel support frames as shown in Figure 7 and attach nut finger
tight after each screw is inserted.
5. After all screws are inserted, tighten nuts firmly.
CAUTION: DO NOT OPERATE heater without support frame assembled to tank.
Figure 6
Screw
Handle
