22
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
14 . PARTS LIST (RMC-KFA 45T/65T/120T/170T Models Only)
KEY NO. DESCRIPTION
PART NO.
RMC-KFA45T RMC-KFA65T RMC-KFA120T RMC-KFA170T
1 Fuel Tank Assembly 2151-0005-00 2151-0005-00 2151-0002-00 2151-0001-00
2 Fuel Gauge 2156-0005-00 2156-0005-00 2156-0001-00 2156-0001-00
3 Fuel Filter Assembly 2155-0005-00 2155-0005-00 2155-0001-00 2155-0001-00
4 Fuel Cap 2151-0003-00 2151-0003-00 2151-0003-00 2151-0003-00
5 Power Cord 3980-0031-00 3980-0031-00 3980-0031-00 3980-0031-00
6 Cord Bushing 3712-0011-00 3712-0011-00 3712-0011-00 3712-0011-00
7 Power Switch 39A0-0044-00 39A0-0044-00 39A0-0044-00 39A0-0044-00
8 Display P.C.B Assembly 215A-0005-00 215A-0005-00 215A-0005-00 215A-0005-00
9 Button Support 3713-0045-00 3713-0045-00 3713-0045-00 3713-0045-00
10 Thermostat Control Knob 3231-0072-00 3231-0072-00 3231-0072-00 3231-0072-00
11 Lower - Shell 3111-0087-00 3111-0087-00 3111-0031-00 3111-0083-00
12 Bushing - Grommet 3712-0004-00 3712-0004-00 3712-0004-00 3712-0004-00
13 Bushing - Cover 3712-0035-00 3712-0035-00 3712-0035-00 3712-0035-00
14 Air Line 3341-0007-00 3341-0005-00 3341-0002-00 3341-0004-00
15 Temperature Limit Control 2153-0003-00 2153-0003-00 2153-0001-00 2153-0001-00
16 Combustion Chamber 2152-0019-00 2152-0013-00 2152-0002-00 2152-0008-00
17 Burner Head Assembly 2152-0020-00 2152-0016-00 2152-0006-00 2152-0009-00
17-1 Nozzle FA1001 FA1002 FA1003 FA1004
17-2 Nozzle Seal Washer ----- ----- 4349-0016-00 4349-0016-00
17-3 Nozzle Seal Spring ----- ----- 3431-0010-00 3431-0010-00
17-4 Nozzle Sleeve ----- ----- 3311-0002-00 3311-0002-00
17-5 Burner Head 3531-0010-00 3531-0010-00 3531-0007-00 3531-0009-00
17-6 Nipple 3541-0039-00 3541-0039-00 3541-0020-00 3541-0020-00
17-7 Spark Plug FA1008 FA1008 FA1009 FA1009
17-8 Fiber Washer 4349-0017-00 4349-0017-00 4349-0017-00 4349-0017-00
17-9 Spring Washer 4342-0009-00 4342-0009-00 4342-0009-00 4342-0009-00
17-10 Flange Bolt 4329-0013-00 4329-0013-00 4329-0013-00 4329-0013-00
18 Fuel Line 3341-0009-00 3341-0009-00 3341-0008-00 3341-0008-00
19 Photocell Assembly FA1007 FA1007 FA1007 FA1007
20 Photocell Bracket 3131-0244-00 3131-0159-00 3131-0159-00 3131-0159-00
21 Screw(BH1) 4311-0068-00 4311-0068-00 4311-0068-00 4311-0068-00
22 Motor and Pump Assembly 2154-0008-00 2154-0008-00 2154-0002-00 2154-0006-00
22-1 Motor 3970-0034-00 3970-0034-00 3970-0029-00 3970-0033-00
22-2 Motor Supportor 3121-0189-00 3121-0189-00 3121-0150-00 3121-0150-00
22-3 Pump Body 3541-0022-00 3541-0022-00 3541-0022-00 3541-0022-00
22-4 Bolt(PH) 4321-0038-00 4321-0038-00 4321-0038-00 4321-0038-00
22-5 Insert See 22-6 See 22-6 See 22-6 See 22-6
