USB-1608HS User's Guide Installing the USB-1608HS
11
Additional documentation
In addition to this hardware user's guide, you should also receive the Quick Start Guide (available in PDF at
www.mccdaq.com/PDFmanuals/DAQ-Software-Quick-Start.pdf ). This booklet supplies a brief description of
the software you received with your USB-1608HS and information regarding installation of that software.
Please read this booklet completely before installing any software or hardware.
Unpacking the USB-1608HS
As with any electronic device, you should take care while handling to avoid damage from static
electricity. Before removing the USB-1608HS from its packaging, ground yourself using a wrist strap or by
simply touching the computer chassis or other grounded object to eliminate any stored static charge.
If your USB-1608HS is damaged, notify Measurement Computing Corporation immediately by phone, fax, or
e-mail. For international customers, contact your local distributor where you purchased the USB-1608HS.
 Phone: 508-946-5100 and follow the instructions for reaching Tech Support.
 Fax: 508-946-9500 to the attention of Tech Support
 Email: [email protected]
Installing the software
Refer to the Quick Start Guide for instructions on installing the software on the Measurement Computing Data
Acquisition Software CD. This booklet is available in PDF at
www.mccdaq.com/PDFmanuals/DAQ-Software-
Quick-Start.pdf .
Installing the hardware
Be sure you are using the latest system software
Before you install your USB-1608HS, run Windows Update to update your operating system with the latest
USB drivers.
Connecting the AC power adapter
Power to the USB-1608HS is provided with the 5 V adapter (PS-5V2AEPS). To connect the power supply to
your USB-1608HS, connect the power adapter cord to the power connector on the USB-1608HS device, and
plug the AC adapter into a power outlet.
The power LED on the device lights up when the USB-1608HS is receiving power from the AC power adapter.
Connecting the USB-1608HS to your system
To connect the USB-1608HS to your system, turn your computer on, and connect the USB cable to a USB port
on your computer or to an external USB hub connected to your computer. The USB cable provides
communication to the USB-1608HS.
When you connect the USB-1608HS for the first time, a Found New Hardware dialog opens when the USB-
1608HS interface is detected.
When the dialog closes, the installation is complete. The activity LED on the USB-1608HS should flash and
then remain lit, indicating the USB-1608HS is communicating with your computer.
Caution! Do not disconnect
any device from the USB bus while the computer is communicating with the
USB-1608HS, or you may lose data and/or your ability to communicate with the USB-1608HS.
