FEATURES

High Efficiency:

91% @ 12Vin, 5V/15A out

Size: 30.5x27.9x11.4mm

(1.20”Ч1.10”Ч0.45”) -- Vertical

30.5x27.9x12.9mm

(1.20”Ч1.10”Ч0.51”) -- Horizontal

Voltage and resistor-based trim

No minimum load required

Output voltage programmable from

0.9Vdc to 5.0Vdc via external resistors

Fixed frequency operation

Input UVLO, output OCP, SCP

Power good output signal

Remote ON/OFF (default: Positive)

ISO 9000, TL 9000, ISO 14001 certified

manufacturing facility

UL/cUL 60950-1 (US & Canada)

Recognized, and TUV (EN60950-1)

Certified

CE mark meets 73/23/EEC and 93/68/EEC

directives

APPLICATIONS

Delphi NC15 Series Non-Isolated Point of Load
DC/DC Power Modules: 12Vin, 0.9V-5.0Vout, 15A

The Delphi NC15 Series, 12V input, single output, non-isolated point of
load DC/DC converters are the latest offering from a world leader in
power systems technology and manufacturing ― Delta Electronics, Inc.
The NC15 series operates from a 12V nominal input, provides up to 15A
of power in a vertical or horizontal mounted through-hole package and
the output can be resistor- or voltage-trimmed from 0.9Vdc to 5.0Vdc. It
provides a very cost effective point of load solution. With creative design
technology and optimization of component placement, these converters
possess outstanding electrical and thermal performance, as well as
extremely high reliability under highly stressful operating conditions.

DATASHEET
DS_NC12S15A_01102008

DataCom

Distributed power architectures

Servers and workstations

LAN / WAN applications

Data processing applications

OPTIONS

Vertical or horizontal versions

Negative ON/OFF logic
