15
Table 4 – Band Crawler Parts Breakdown
Item Description Part Number Qty.
1 End Plug 05-0116-021 1
2 Name Plate 01-0209-025 1
4 Grease Zerk 01-0469-003 1
5 Crawler Body 05-0116-013 1
6 Connector 05-0116-012 1
7 Set Screw 05-0116-011 1
8 Rear Ball Leg Assembly 05-0116-010 1
9 Eccentric Torch Holder 05-0116-008 1
10 Front Ball Leg Assembly 05-0116-020 1
11 Worm Shaft Assembly 05-0116-007 1
11A Bearing Housing 05-0116-117 1
12 Hex Head Cap Screw, 1/4-28NF x 2” Lg. 10-14F0-200 4
13 Flat Washer, 1/4” 12-0014-F00 4
14 Drive Wheel Assembly 05-0116-083 4
15 Rear Flange Leg Assembly 05-0116-001 1
16 Bearings, Worm Gear Shaft Assembly 05-0116-003 4
17 Worm Gear Assembly Shaft 05-0116-002 2
18 Front Flange Leg Assembly 05-0116-004 1
19A 9 Foot Flexible Drive Shaft Assembly 05-0116-022 1
19B 14 Foot Flexible Drive Shaft Assembly 05-0116-031 1
20 #8-32 SCK’T Set Screw x 1/4” 19-08C0-014 4
21 Latch Assembly 05-0116-040 2
21A Short Anchor Block 05-0116-061 1
21B Latch Handle 05-0116-016 1
21C Long Anchor Block 05-0116-046 1
21D Rivet 17-3160-100 2
21E Tension Nut 1H-14F0-000 1
21F Latch Spring 01-0183-013 1
21G Anchor Pin 05-0116-036 1
21H Long Latch Pin 1L-14FO-000 1
21I Anchor Pin 04-0106-023 1
22 Shim 05-0116-030 1
