22
KEY PARTS AND SAFETY FEATURES ON YOUR SAW
BACK VIEW
13. Fence Holders
14. Motor Cover
15. Dust
Spout
16. Slide Plate
17. Mobile Base Foot Pedal
18. Blade Wrenches
FRONT VIEW
1. Table
Top
2. Extension Wings
3. Blade Guard/Splitter/Anti-Kickback
Pawl Assembly
4. ON/OFF Switch
5. Elevation Hand Wheel
5a. Elevation Hand Wheel Lock Knob
6. Tilt Hand Wheel
7. Miter Gauge
7a. Miter Gauge Lock
8. Miter Gauge Slot
9. Tilt Angle Scale
10. Rip Fence
11. Rip Fence Lock
12. Extension Table
2
1
11
2
10
9
8
7
6
5
4
3
5a
7a
12
13
14
15
16
17
18
