Option

When Destination Window is Resized or

Moved

Relative to Window
Top Left

The start point will stay the same distance from the
top left corner of the window.

Relative to Window
Top Right

The start point will stay the same distance from the
top right corner of the window.

Relative to Window
Top Percentage of
Width

The start point will stay the same distance from the
top of the window, but it’s horizontal position will be
a percentage of the window’s width..

Relative to Window
Bottom Left

The start point will stay the same distance from the
bottom left corner of the window.

Relative to Window
Bottom Right

The start point will stay the same distance from the
bottom right corner of the window.

Relative to Window
Bottom Percentage
of Width

The start point will stay the same distance from the
bottom of the window, but it’s horizontal position will
be a percentage of the window’s width..

Relative to Screen
Top Left

The start point will stay the same distance from the
top left corner of the screen, no matter what the size
or position of the window.

For example, let’s say that a particular application has an onscreen jog control in the lower right hand
corner of it’s Timeline window, and the center of that control is 100 pixels from the right of the window and
20 pixels from the bottom of the window. When the window is resized, the control stays at 100 pixels from
the right and 20 pixels from the bottom of the window.

Suppose the only way to access this program’s jog function is by dragging this control left or right. You
could program the MCS5 Jog Wheel to do a horizontal drag starting at 100, 20 Relative to Window
Bottom Right.

Once you have chosen from the Starting Location popup, you will be prompted to actually pick the
starting point.
