Datalogic Scanning C-BOX 300 User Manual
Page 5

CONTENTS
GUIDE TO INSTALLATION ........................................................................ iv
SAFETY PRECAUTIONS............................................................................ ix
GENERAL FEATURES ................................................................................ 1
Electrical Connections and Hardware Setup................................................. 6
Scanner Chassis Grounding Jumper Settings ............................................ 11
Profibus Connections and Setup................................................................. 12
Profibus Node Address Selection ............................................................... 12
Profibus Connector (9-Pin Female External Connector) ............................. 12
Connection to a Profibus Network............................................................... 13
C-BOX 3X0 Configuration for Profibus DP Slave Node .............................. 14
Configuration Switch And 9-Pin Internal Connector............................................ 15
GET/TEST/SEND Functions ....................................................................... 18
Special Notes for Matrix Reader Setup....................................................... 22
C-Box 3x0 Configuration for Matrix-2000™ Readers.................................. 22
C-Box 3x0 Configuration for Matrix-1000™ Readers.................................. 23
TECHNICAL FEATURES ........................................................................... 25
iii
