INSTALLATION
2
The internal LEDs of the C-BOX 3X0 (see Figure 15) indicate the following:
POWER ON
(
PWR
)
(red) indicates the C-BOX 3X0 is connected to the power
supply and the power switch is ON.
WARNING
(
WL
)
(red) indicates a warning or error condition. It is ON when
a connection procedure is in progress (the system is
busy), during a GET/TEST/SEND procedure or during the
Configuration Mode. It blinks when an error condition
occurs. Normally this LED should be OFF.
BUS ACTIVITY
(
BA
)
(green) indicates the Profibus Network activity. When
communication takes place, this LED will blink slightly.
TRANSMISSION
(
TX
)
(green) indicates there is communication between the
Application and the DeviceNet module. Upon
communication, this LED will blink slightly.
MODULE STATUS
(
MS
)
(green) OFF = Bus off-line or power not supplied.
ON = Bus in Data Exchange Mode.
Flashing = Bus in Clear Mode.
(red)
OFF = No error or power not supplied.
ON = Error in initialisation of Profibus ASIC.
Flashing = Error in configuration data and / or in
user parameter data.
POWER POLARITY ERROR
(red) indicates a wrong polarity. While activated, all other
LEDs will be off until the power feed is connected with
correct polarity.
