UK
Inclination sensor JN
5
The connection terminals may only be supplied with the signals indicated in the
technical data and/or on the device label and only the approved accessories from
ifm may be connected.
2.4 Tampering with the device
Contact the manufacturer in case of malfunction of the unit or uncertainties.
Any tampering with the device can seriously affect the safety of operators and
machinery. In case of tampering with and/or modifying the unit, any liability and
warranty is excluded.
3 Functions and features
The 2-axis inclination sensor with CANopen interface enables angle levelling and
position detection of mobile machines.
Typical applications are, for example, the position detection of access platforms,
levelling of mobile cranes or set-up of mobile machines.
Properties:
● 2-axis inclination sensors with a measuring range of 360° (+/- 180°)
● High accuracy and resolution
● CANopen interface to CiA DS-301 and device profile CiA DSP-410
● The module supports "node guarding" and "heartbeat"; "guard time", "life time
factor" as well as "heartbeat time" can be configured.
● High sampling rate and band width
● Configurable limit frequency (digital filter) for vibration suppression
● CANopen functions
– Transmit PDOs (RTR, cyclical, synchronised)
– SYNC consumer (synchronised transmission of the transmit PDOs after
reception of a SYNC telegram)
– EMCY producer (exceeding of limit value, monitoring of the inside device
temperature)
– Failure monitoring by means of heartbeat or node guarding / life guarding
● Simultaneous inclination and vibration measurement possible
● Programming key
● Autostart function
