Inclination sensor JN
32
13 Maintenance, repair and disposal
The unit is maintenance-free.
► Dispose of the device in accordance with the national environmental
regulations.
14 Approvals/standards
The CE declarations of conformity and approvals can be found at:
www.ifm.com → Data sheet search → JN2100
15 Factory setting
SDO
index
Sub-
index
Type Value Delivery
0x2000 0x0 u8 Node ID 10
0x2001 0x0 u16 Baud rate 125 Kbits
0x2040 0x0 u8 Flag for quadrant correction 2: corresponds to "0° ... 360°"
0x2041 0x0 u8 Flag for heating 1: corresponds to "heating on"
0x2042 0x0 u8 Index teach value of the X/Y/Z axes 2: corresponds to "absolute
measurement"
0x2043 0x0 u8 FIR filter step angle 2: corresponds to "FIR lowpass
5Hz"
0x2044 0x0 u8 Angle calculation 0: corresponds to "perpendicular"
0x2045 0x0 u8 CAN 120 Ω terminating resistor 1: corresponds to "activated"
0x2046 0x0 u8 Set zero point of the X/Y axes 2: corresponds to "absolute
measurement"
0x2047 0x0 u8 Output value 0: corresponds to "angle"
0x2048 0x0 u8 Axis selection for Veff & aPeak 7: corresponds to "X/Y/Z" activated
0x2049 0x0 u8 FIR filter for vibration measurement 5: corresponds to "10...400 Hz"
0x204A 0x0 u8 Measuring range for vibration
measurement
2: corresponds to "8g"
0x6000 0x0 u16 Resolution 100d: corresponds to "0.1°"
