1.2.2 Packet Format
Header Size Command Data CRC
2 bytes 1 byte 1 byte 0 – 64 bytes 2 bytes
Header
bytes indicate start of the packet.
Size
specifies number of bytes for data field.
CRC
verifies data integrity for header, size, command and data bytes.
Command
identifies action, which is required to be performed on the data.
1.2.3 CRC
Protocol uses 16-bit CCITT CRC to verify data integrity.
P(x) = X16+X12+X5+1.
unsigned calc_crc(unsigned char *data, unsigned n, unsigned start)
{
unsigned I, k, q, c, crcval;
crcval=start;
for (I=0; I
{
c=data(I) & 0xFF;
q=(crcval^c) & 0x0F;
crcval=(crcval>>4)^(q*0x1081);
q=(crcval^(c>>4)) & 0x0F;
crcval=(crcval>>4)^(q*0x1081);
}
return crcval;
}
1.2.4 Communications flow
Communication between PC and MCU utilizes Master-Slave
model, where PC is a master, and MCU is a slave.
Master sends requests to the slave, and slave has to reply to
them. Slave acts like a passive device and cannot send any
requests to the master.
