IBD185 User Guide

I2C Bus Initialize

Initialize the I2C bus master on MCU.

Start up an I2C bus with specific Bus ID and Speed.

The Bus ID can be 1 or 2.

Bus ID is 1 means the I2C1 on MCU, and so on.

The Speed can be 0, 1, 2.

Speed=0 means de-initialize the I2C Bus.

Speed=1 means initialize the specific I2C Bus in 400Kbps.

Speed=2 means initialize the specific I2C Bus in 100Kbps (default).

Sub Command Request

Sub

Command

Length

Sub Command

Code

Sub Command

Data

size of the

I2cApiBusInit

structure

I2CAPI_BUS_INIT I2cApiBusInit structure

Sub Command Reply

Sub

Command

Length

Sub Command

Code

Sub Command

Data

size of the

I2cApiBusInit

structure +1

I2CAPI_BUS_INIT I2cApiBusInit structure followed by

one byte I2cApiResult

The reply packet contains the parameters that device received and

followed by one byte of result.

I2cApiResult = 0 means the execution result is fail.

I2cApiBusInit Structure

Field Type

Description

Bus ID

byte

Designate which I2C bus on MCU

1 – 1st I2C bus master

2 – 2nd I2C bus master

Bus Speed

byte

I2C bus speed selection

0: De-Initialize the specific I2C bus

1: 400Kbps

2: 100Kbps (default)
