IBD185 User Guide

25

Read 8 bytes from address 0x00 on 24C02

REQUEST PACKET:

Header Size Command

0xFF,

0xEE

8 0x8E

Data CRC

Sub

Cmd

Len

Sub

Cmd

Code

Sub Cmd Data

6 0x05

BudID SlvAdd CmdLen CmdCode

0x01

(I2C1)

0xA0

(0x50

<<1)

1

0x00

(reading

from 0x00)

Flag DatLen

0

8

0xD0,

0x5E

REPLY PACKET:

Header Size Command

0xFF,

0xEE

16 0x8E

Data CRC

Sub

Cmd

Len

Sub

Cmd

Code

Sub Cmd Data

14 0x05

BudID SlvAdd CmdLen

0x01

(I2C1)

0xA0

(0x50

<<1)

1

Flag DatLen

Result DatBuff

0

8 8

(Result==

DatLen

means

success)

0x00,0x01,

0x02,0x03,

0x04,0x05,

0x06,0x07

0xD9,

0xD0
