www.desatech.com 108661-01F 33
PARTS LIST
MODELS (V)T32N, (V)T32Nb, (V)T32NR, (V)T32NRb, (V)T32P, (V)T32Pb, (V)T32PR, (V)T32PRb
AND CHDv32NR
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions listed under Replacement Parts
on page 30 of this manual.
KEY
NO.
PART NO. DESCRIPtION qtY.
1 ** Firebox Assembly 1
** Face Weldment 1
3 10889-01 Door Assembly (T & CHDV Models Only) 1
10889-0 Door Assembly (VT Models Only) 1
4 109155-01 Top Stamped Panel Assy T3N/P, T3NB/PB Models 1
108903-01 Top Rolled Louver Assy T3NR/PR, T3NRB/PRB & CHDV3NR Models 1
5 109155-0 Bottom Stamped Panel Assy T3N/P, T3NB/PB Models 1
108903-0 Bottom Rolled Louver Assy (T3NR/PR, T3NRB/PRB, CHDV3NR Models) 1
6 108895-01 Fireplace Top 1
7 109096-01 Fireplace Top Insulation 1
8 ** Fireplace Surround 1
9 108885-01 Burner Assembly (Natural) 1
108885-0 Burner Assembly (Propane/LP) 1
9-1 1110 Screw #8-3 x 3/8 PPH Zinc
9- 11105 Screw #10 x 1/ Zinc 9
9-3 11179 Screw #10-4 x 1/4 Zinc 4
9-4 1137 Screw, Trilab M4 x 8mm 1
9-5 14389 Millivolt Valve (Natural) 1
14390 Millivolt Valve (Propane/LP) 1
9-6 1449 Piezo Ignitor 1
9-7 14500 Brass Fitting
9-8 1453 Flexible Connector 1
9-9 14511 Ignitor Bracket 1
9-10 1458 Brass Elbow Fitting 1
9-11 104506-5 Orifice (Natural) 1
14514 Orifice (Propane/LP) 1
9-1 104509-0 Aluminum Tubing Assy 1
9-13 6808 Valve Bracket 1
9-14 687 Switch Bracket 1
9-15 108886-01 Base Grate Assembly 1
9-16 108891-01 Burner 1
9-17 108084-0 Pilot Assembly (Natural) 1
108084-03 Pilot Assembly (Propane/LP) 1
9-18 108889-01 Burner Base Assembly 1
9-19 7113 Air Deflector 1
10 108890-01 Burner Base Gasket 1
11 108897-01 Rear Refractory Brick Panel (B Models Only) 1
1 10908-03 Heat Shield 1
13 108901-01 Right Refractory Brick Panel (B Models Only) 1
14 108901-0 Left Refractory Brick Panel (B Models Only) 1
15 11418 Push-On Nut
16 108440-01 Screen
17 109479-01 Screen Rod 1
18 1413 Strain Relief 1
19 1171 Gas Knock-Out Cover
0 4353 Handy Box Assembly 1
1 4460 Gas Conduit Assembly 1
109-01 Log Set 1
-1 109403-01 Front Log (Log 1) 1
- 109404-01 Rear Log (Log ) 1
-3 109407-01 Base Log (Log 3) 1
-4 109406-01 Crossover Log (Log 4) 1
-5 109405-01 Left Top Log (Log 5) 1
-6 109408-01 Right Top Log (Log 6) 1
PARTS AVAILAbLE - NOT SHOWN
5487 Lava Rock/Bag Assy 1
753 Notice Label 1
5540 Vent Label 1
PCDM-3T Conversion Kit (CHDV3NR only) 1
** Not a field replaceable part.
