www.desatech.com 108661-01F 4
OPERATING FIREPLACE
Continued
OPTIONAL HAND-HELD
REMOTE OPERATION
Note: All remote control accessories must be purchased sepa-
rately (see Accessories, page 31). Follow instructions included
with the remote control.
NOtICE: You must light the pilot before using the
hand-held remote control unit. See Lighting Instruc-
tions, page 23.
After lighting, let pilot flame burn for about one minute. Turn
control knob to ON position. Adjust flame adjustment knob
anywhere between HI and LO. Slide the selector switch to the
REMOTE position (see Figure 51). Note: The burner may light
if hand-held remote was on when selector switch was last turned
off. You can now turn the burner on and off with the hand-held
remote control unit.
IMPORTANT: Do not leave the selector switch in the REMOTE
or ON position when the pilot is not lit. This will drain the
battery.
tHERMOStAt SERIES MODEL HRC200
The hand-held remote can be operated using either the manual
mode (MANU) or thermostatic mode (AUTO) (see Figure 53).
To select Fahrenheit/Centigrade mode display, carefully press
the ˚C/˚F mode button with the end of a paper clip or similar
blunt object.
Figure 52 - On/Off Hand-Held Remote Control Unit HRC100
Control
Button
Indicator
Light
Figure 53 - Thermostat Hand-Held Remote Control Unit
HRC200
LOCK
MANU AUTO
ºC/ºF
TEMP POWER
ROOM
TEMP SET
TEMP
AUTO
Turns Hand-Held
Remote On or Off
and Allows You to
Choose the Manual
Setting
Selects
AUTO Mode
°C/°F Mode Button
Locks System to
Prevent Accidental
Ignition
Turns Burners
On or Off
Increases or
Decreases Room
Temperature in
AUTO Mode
Digital Display Shows
Temperature and Settings
ON/OFF SERIES MODEL HRC100
Hold the control button on the hand-held remote until burner
turns on. Hold the control button again until burner turns off
(see Figure 52).
tO LOCK press both buttons on hand-held remote control until
light stops flashing. Hand-held remote control is now locked. If
the fire is on it will be turned off automatically. In the locked
state, the light will not light up when any button is pressed.
tO UNLOCK press both buttons together on hand-held remote
control until the light stops flashing. The hand-held remote is
now unlocked.
OF
F PIL
O
T
LO
IH
ON OFF REMOTE
ON
OFF
O
N
Selector Switch in
Remote Position
Figure 51 - Setting the Selector Switch, Gas Control Knob
and Variable Contorl Knob for Remote Operation
Blower Control Knob
(Optional Accessory)
Gas Control Knob
in ON Position
Variable
Control Knob
Manual Mode
1. Press the POWER and LOCK buttons together to turn on
the hand-held remote control.
2. Press the MANU button to turn on the fireplace.
3. Press the POWER and LOCK buttons together to turn off
the fireplace.
Auto (Thermostatic) Mode
1. Press the POWER and LOCK buttons together to turn on
the hand-held remote control.
2. Press AUTO button to select this mode.
3. Set the desired room temperature by pressing the TEMP
+ or - buttons.
4. Press the POWER and LOCK buttons together to turn off
the fireplace
Note: Do not leave the hand-held remote in the AUTO mode
close to the fireplace. The radiant heat from the fireplace will
turn off the fireplace. Ideally, place the hand-held remote in the
center of the room facing towards the fireplace.
Note: Do not hold the hand-held remote for a long time. Body
temperature will affect its operation in the AUTO mode.
Safety Features
When away from home for an extended period of time or as
a child safety feature to prevent accidental ignition of the fire-
place, the receiver ON/OFF/REMOTE switch should be in the
OFF position.
Auto Shutoff Feature
1. If the average room temperature exceeds 82° F (28° C), the
hand-held remote control will perform a safety override
and shut the fireplace off. This feature is not available in
the MANU mode.
2. The receiver continuously receives signals from the hand-
held remote to control the room temperature. If the hand-
held remote is misplaced, obstructed or for any reason
cannot transmit to the receiver, the receiver will shut off
the fireplace after 8 minutes.
