FIREPLACE INSTALLATION
Continued
3. Place log #3 (crossover log) onto the rear and front logs. Make
sure it is seated properly on the smooth surface on the front log
and on the pin on the back log as shown in Figure 46.
4. Place log #4 (right log) on the pin on the right side of front log
as shown in Figure 47.
5. Place log #5 (base log) onto the front left part of the grate
making sure the notches fit over the prongs of the grate). See
Figure 48.
6. Place log #6 (left log) onto two pins on the left side of back
and front log. See Figure 48.
7. Place lava rock along sides and front of firebox bottom in areas
that are visible only. It is not necessary to use all of the lava
rock provided.
NOtICE: Do not put lava rock on burner or under burner.
Placing lava rock on burner will cause performance
problems.
8. Pull ember material apart into pieces no larger than a dime.
Place these pieces loosely and sparingly directly onto the ex-
posed section of the front burner and along the space between
the burner and grate prongs (see Figure 49). This will create
the glowing ember appearance as the flame touches the ember
material. Do not block air slots by using too much ember
material in one area. It is not necessary to use all of the ember
material provided.
9. Close glass door, lock door latches, replace screen and close
louvers (see steps 5 and 7 of Removing/Replacing Glass Door,
page 20).
WARNING: The glass door must be securely in place
before running this fireplace. Do not run this fireplace
if glass is missing or broken.
4
Ember Material
Figure 49 - Placing Ember Material on Burner
Figure 47 - Installing Log No. 4
5
6
Figure 48 - Installing Logs No. 5 and No. 6
3
Figure 46 - Installing Log No. 3
