Model 585 Time Scaling Processor
Getting Started
2-11
2.6.3 System
Settings
In the
System Settings
menu, the options are
Display Mode
and
Brightness.
Brightness
You can use the
Brightness
menu to adjust the intensity of the display. Changes
you make in this menu are activated immediately, without pressing
Enter
.
Display Mode
Use
Display Mode
to choose the unit of adjustment displayed for pitch shifting:
frames
,
¢ (cents)
, or
% (percent)
.
Frame mode uses percent as the unit of adjustment. Adjustments are in increments of
0.1 percent. An additional setting of
+4.17%
is included, for pitch shifting
presentations recorded at 25 fps but played back at 24 fps. The frame mode display
also indicates when the setting is appropriate for pitch shifting presentations recorded
at 24 fps but played back at 25 fps.
Cents represent musical cents, where 100 cents equals one semitone, and 1,200 cents
equals one octave. Model 585 offers a shifting range of –282 to +242 cents.
Percent mode operates in the same manner as frame mode in all but two ways: it lacks
the additional +4.17% setting, and does not indicate the values appropriate for
conversions between frame rates.
