Model 585 Time Scaling Processor Getting Started
2-4
2.3.3 Remote Connection Ports
The Remote (9-pin) In and Remote (9-pin) Out ports are reserved for future
enhancements.
2.4 Front Panel
The front panel is shown with feature definitions in Figure 2-3.
Menu display shows the current function mode
Knob for adjustment of
settings and menu navigation
Buttons for
function selection, and adjustment of settings menu navigation, LEDs indicate when
specific modes are in use
Figure 2-3 Model 585 Front Panel
The menu system has two independent structures: setup and status. The setup menu
lets you control and configure Model 585 to suit your requirements. The status menu
displays information regarding the operating status.
There are two ways to adjust settings on Model 585. All functions are adjustable
using the buttons below the display window, and some functions can be easily
adjusted using the knob.
