Section 1 - Product Overview
Hardware Overview
Front View
Power Button:
Press once to power on the DNS-323. Press and hold the button until it begins to blink to power down the DNS-323.
Drive Lights:
These lights will be solid BLUE when drives are connected but inactive. The lights will blink when the drives are being
accessed, formatted or synchronized. They will illuminate AMBER if a drive has failed.
Network Activity Light:
The Activity Light will be solid BLUE when there is an Ethernet connection. It will blink to indicate LAN traffic.
Power Button
Drive Light
Drive Light
Network Activity Light
