13
Groth Model 2300A Pressure/Vacuum Relief Valve
Fig. 13
Epoxy Vinyl Ester Resin
ITEM NAME 411-45 411-45 w/ Kynar 470-36 Furan
1 Body 411-45 411-45 470-36 Furan
2 Weatherhood 411-45 411-45 470-36 Furan
3 Stem Alloy C276 PVDF Alloy C276 Alloy C276
4 Hex Nut 316 SS 316 SS 316 SS 316 SS
5 Flat Washer 316 SS 316 SS 316 SS 316 SS
6 Lock Washer 316 SS 316 SS 316 SS 316 SS
7 Hex Nut 316 SS 316 SS 316 SS 316 SS
8 Weatherhood Post Alloy C276 Alloy C276 Alloy C276 Alloy C276
9 Screen PVC PVC PVC PVC
10 Pallet 411-45 PVDF 470-36 Furan
11 * Diaphragm FEP FEP FEP FEP
12 Retainer Plate 411-45 PVDF 470-36 Furan
13 Hex Nut Alloy C276 Not Used Alloy C276 Alloy C276
14 Flat Washer Alloy C276 Not Used Alloy C276 Alloy C276
15 Lock Washer Alloy C276 Not Used Alloy C276 Alloy C276
21 Hex Nut (NS) Not Used Fluoropolymer Not Used Not Used
* = Recommended Spare Parts
Refer to Fig. 5 & 6 on p. 6 for pallet assembly fastener information.
