462077 • Model USGF Ultimate Steel Grease Fan, Rev. 2, June 2008

Greenheck warrants this equipment to be free from defects in material and workmanship for a period of one year from

the purchase date. Any units or parts which prove defective during the warranty period will be replaced at our option

when returned to our factory, transportation prepaid. Motors are warranted by the motor manufacturer for a period of

one year. Should motors furnished by Greenheck prove defective during this period, they should be returned to the

nearest authorized motor service station. Greenheck will not be responsible for any removal or installation costs.

As a result of our commitment to continuous improvement, Greenheck reserves the right to change specifications

without notice.

Greenheck Catalog USGF provides additional information

describing the equipment, fan performance, available

accessories, and specification data.

Phone: (715) 359-6171 • Fax: (715) 355-2399 • E-mail: [email protected] • Website: www.greenheck.com

Warranty

AMCA Publication 410‑96, Safety Practices for Users and

Installers of Industrial and Commercial Fans, provides

additional safety information. This publication can be

obtained from AMCA International, Inc. at: www.amca.org.

Parts List

NOTE: Each fan bears a manufacturer’s nameplate with model number and serial number embossed. This information will

assist the local Greenheck representative and the factory in providing service and replacement parts. Before taking any

corrective action, make certain unit is not capable of operation during repairs.
*For replacement, the windband, vertical supports, drain trough and curb cap/venturi come as one complete assembly.

CAUTION: A fan manufactured with an explosion resistant motor does not certify the entire unit to be explosion proof.

MOTOR PULLEY

HOOD

MOTOR

HOODBAND

BREATHER
TUBE

SHOCK
MOUNTS (4)

*WINDBAND

WHEEL

*CURB CAP/VENTURI

*DRAIN TROUGH

CONDUIT
CHASE

*VERTICAL
SUPPORTS

DRIVE
FRAME
ASSEMBLY

FAN SHAFT

BEARINGS

SHAFT PULLEY

BELT

LIFTING LUGS
