F 10 Pneumatic Positioner
Where to Find Information
Page
Product Description 1
Operating Principle 2
Installation, Rotary Actuators
- Mechanical 3
- Pneumatic, Double Acting 3
- Pneumatic, Single Acting 4
- Air Supply Requirement 4
Installation, Linear Actuators
- Mechanical installation 5
- Pneumatic installation 6
Calibration
- Initial Settings 7
- Cam Changes 7
- Zero Adjustment 8
- Range Adjustment 8
Trouble Shooting 9
General Specification:
Metric Imperial
Hysteresis : 0.6%
Linearity : 1.0%
Air Flow : 210 Nl/min (at 6 bar) : (7.4 SCFM at 87 psi)
Air Consumption : 15 Nl/min (at 6 bar) : (0.6 SCFM at 87 psi)
Min. volume
actuator
: 0.1 Nl : 6.1 in 3
Temperature : -20° to +80° C : (-4° to +176°F)
Enclosure : IP54 (option IP65) : NEMA 3 (option NEMA 4)
Mounting : VDI/VDE 3845 or
IEC 534/6
Air Entry : G 1/4" : (1/4" NPT)
Air Supply : 1.4 to 8.6 bar : (21 to 125 psi).
Input Signal
-
Standard : 0.2 to 1.0 bar : (3 to 15 psi).
- Adjustable : 0.2 to 0.6 bar : (3 to 9 psi).
: 0.6 to 1.0 bar : (9 to 15 psi).
Media : Non-lubricated instrument air, filtered at 25 micron.
: Dew point should be 10°C (18°F) below enviromental temperatur.
: Air quality class 3-2-3 accord. to ISO 8573-1.
