PART NUMBERING SYSTEM
H 48 S V 050 20 N R F A
Form
Factor
Input
Voltage
Number of
Outputs
Product
Series
Output
Voltage
Output
Current
ON/OFF
Logic
Pin Length Option Code
H - Half Brick 48V S- Single V- Value line 050- 5V 20- 20A N- Negative
P- Positive
R- 0.170”
N- 0.145”
K- 0.110”
F- RoHS 6/6
(Lead Free)
A- Standard
Functions
MODEL LIST
MODEL NAME INPUT OUTPUT EFF @ 100% LOAD
H48SV3R310NRFA 36V~75V 1.3A 3.3V 10A 89.5%
H48SV3R320NRFA 36V~75V 2.5A 3.3V 20A 90.0%
H48SV3R330NRFA 36V~75V 3.7A 3.3V 30A 90.5%
H48SV3R340NRFA 36V~75V 4.9A 3.3V 40A 89.5%
H48SV05010NRFA 36V~75V 1.9A 5.0V 10A 88.5%
H48SV05020NRFA 36V~75V 3.7A 5.0V 20A 90.0%
H48SV05030NRFA 36V~75V 5.5A 5.0V 30A 90.5%
Default remote on/off logic is negative and pin length is 0.170”.
For different remote on/off logic and pin length, please refer to part numbering system above or contact your local sales.
CONTACT : www.delta.com.tw/dcdc
USA:
Telephone:
East Coast: (888) 335 8201
West Coast: (888) 335 8208
Fax: (978) 656 3964
Email:
[email protected]
Europe:
Phone: +41 31 998 53 11
Fax: +41 31 998 53 53
Email:
[email protected]
Asia & the rest of world:
Telephone: +886 3 4526107 ext 6220
Fax: +886 3 4513485
Email:
[email protected]
WARRANTY
Delta offers a two (2) year limited warranty. Complete warranty information is listed on our web site or is available upon
request from Delta.
Information furnished by Delta is believed to be accurate and reliable. However, no responsibility is assumed by Delta for its
use, nor for any infringements of patents or other rights of third parties, which may result from its use. No license is granted
by implication or otherwise under any patent or patent rights of Delta. Delta reserves the right to revise these specifications
at any time, without notice
.
