Delphi Series H48SV, 150W Half Brick Family
DC/DC Power Modules: 48V in, 5V/20A out

The Delphi Series H48SV Half Brick, 48V input, single output, isolated
DC/DC converters are the latest offering from a world leader in power
systems technology and manufacturing — Delta Electronics, Inc. This
product family provides up to 150 watts of power or 40A of output current
(3.3V model) in an industry standard footprint. This product family comes
with standard positive trimming method and utilizes standard trim value.
It also comes with output trimming range between +10% to –20%. All
models are fully protected from abnormal input/output voltage, current,
and temperature conditions. The Delphi Series converters meet all
safety requirements with basic insulation.

OPTIONS

Positive Remote On/Off logic

Short pin lengths available

APPLICATIONS

Telecom/Datacom

Wireless Networks

Optical Network Equipment

Server and Data Storage

Industrial/Testing Equipment

FEATURES

High Efficiency: 90.0% @ 5.0V/20A

Size: 61.0x57.9x12.7mm

(2.40”Ч2.28”Ч0.50”)

Standard footprint

Industry standard pin out

Fixed frequency operation

Metal baseplate

Input UVLO, Output OCP, OVP, OTP

Basic insulation

No minimum load required

2:1 Input voltage range

ISO 9001, TL 9000, ISO 14001, QS 9000,

OHSAS 18001 certified manufacturing

facility

UL/cUL 60950 (US & Canada) Recognized,

and TUV (EN60950) Certified

CE mark meets 73/23/EEC and 93/68/EEC

directives

DATASHEET
DS_H48SV05020_08102007
