33
ILLUSTRATED
PARTS LIST
This list contains replaceable parts used in your generator. When ordering parts,
follow the instructions listed under REPLACEMENT PARTS on page 28 of this
manual.
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 25954000 Gas Cap/Fuel Gage 1
2 099832-01 Gas Tank (with 90
°
fitting) 1
3 25978000 Breather Assembly 1
4 HC4-8C Screw, 1/4-20 x 1" 4
5 099701-01 Screw, M5 x 10 1
6 19508001 Gas Line Clamp 2
7 25985005 Fuel Line 1
8 099743-01 Fuel Filter 1
9 099752-01 Roll Cage
∆
1
099752-02 Roll Cage † 1
10 NTC-4C Lock Nut, 1/4-20 4
11 NEC-5C Lock Nut, 5/16-18 5
12 14138000 Ground Strap 1
13 26020000 Shock Mounts 3
14 WLE-5 Lock Washer, 5/16" 3
15 100406-01 Bolt, 5/16-18 x 3/4" 3
16 WP-5C Flat Washer, 5/16" 7
17 HC5-11C Bolt, 5/16-18 x 1 3/4" 2
18 099756-01 Engine Spreader 1
19 099750-01 Hook Bolt, 5/16-18 ** 2
20 099749-01 Battery Mounting Bracket ** 1
21 NEC-5C Lock Nut, 5/16-18 ** 2
22 100410-01 Sems Screw, #8-18 x 1/2" 4
23 M10908-74 Screw, 1/4-20 x 1/2" 3
24 WP-4C Washer, 1/4" 5
25 01076002 Washer, #10 1
26 WLI-3 Lock Washer, #10 1
27 099965-01 Linkage Cover 1
PARTS AVAILABLE - NOT SHOWN
099866-01 Safety Information Decal * 1
099866-02 Safety Information Decal ** 1
100003-01 Operation Decal * 1
100003-02 Operation Decal ** 1
099873-01 Battery Cable (Positive)** 1
099873-02 Battery Cable (Negative)** 1
HC4-6C Screw, 1/4-20 x 3/4" (For attach-
ing battery cables to battery)
2
03157000 Fuel Line Grommet 3
* For models MGH4000A, MGH5000A, and MGH6000 only
** For model MGH7000 only
∆
For models MGH4000A and MGH5000A only
† For models MGH6000 and MGH7000 only
