POWER CORD AND PLUG REQUIREMENTS
120V, 30-amp twist-lock receptacle
• NEMA L5-30P plug
• Three-wire, 30-amp cord
120/240V, 20 or 30-amp twist-lock receptacle
• NEMA L14-20P (20-amp) or L14-30P (30-amp) plug
• Four-wire, 20-amp or 30-amp cord
W
(Neutral)
X
(Hot)
Ground
(Green)
120 Volt
30 Amp
G
W
X
L5-30P
Plug
w
G
Y
X
w
G
Y
X
120V
120V
Neutral
Ground
Ground
X
(Hot)
W
(Neutral)
Y
(Hot)
Ground
(Green)
L14-30P
Plug
L14-20P
Plug
120V
120V
Neutral
120/240 Volt
20 and 30
Amp
Figure 14 - Cord and Plug Configurations
