Desa SVYD18NRA/PRA SERIES - Manual (Page 23)

www.desatech.com 113084-01A 23
PARTS LIST
This list contains replaceable parts used in your heater. When ordering parts, follow the instructions
listed under Replacement Parts on page 26 of this manual.
KEY PART NUMBER
NO. SVYD18PRA SVYD18NRA DESCRIPTION QTY.
1 104026-01 104026-01 Stove Log 1
2 103778-01 103779-01 ODS Pilot (LP) 1
3 098249-01 098249-01 ODS Nut 2
4 104423-02 104423-01 Burner Outlet Tube 1
5 098264-02 098264-02 Male Connector 1
6 111124-01 111124-01 Burner Retainer Spring 1
7 099056-19 099056-26 Burner Orifice Injector 1
8 102980-01 102980-01 Burner 1
9 099387-13 099387-15 Pilot Tube 1
10 103781-02 103781-01 Gas Control Valve 1
11 103345-02 103345-02 Lower Bracket 1
12 M11084-38 M11084-38 Screw, #8 x .38 7
13 104383-02CK 104383-02CK Painted Base Assy 1
14 098271-10 098271-10 Ignitor Cable 1
15 102445-01 102445-01 Piezo Ignitor 1
16 103587-02 103587-02 Plate, Switch 1
17 098304-01 098304-01 Screw 2
18 103784-04 103784-04 Flame Adjustment Knob Extension 1
19 103784-03 103784-03 Off-Pilot-On Knob Extension 1
20 M12461-26 M12461-26 Screw, Hex Slt Wsr 10-32 x .38 4
21 ––– 100609-01 Pilot Tube (Regulator to Pilot) 1
22 ––– 099918-02 Pilot Regulator 1
23 103284-02 103284-02 Wiring Harness 1
24 099998-01 099998-01 Switch 1
PARTS AVAILABLE — NOT SHOWN
100563-01 100563-01 Warning Plate 1
103877-01 103877-01 Lighting Instructions Plate 1
100565-01 100565-01 Warning Plate Fastener 1
101137-04 101137-04 Hardware Kit 1
