WCAIM2031 AF-17 Electronic Positioner: Installation, Operation and Maintenance 7
3.0 INSTALLATION OF AF-17 INTO SERIES 75 ELECTRIC ACTUATOR
3.1 General
If the actuator was purchased with the AF-17 positioner board factory installed, proceed to section 4.0.
If a 4-20 mA Position Output option is also used with the AF-17 positioner, refer to paragraph 3.3.3 for installation (if not already
installed), and paragraph 3.4.5 for wiring.
3.1.1 Check Kit For Parts
A. Common Parts For Sizes 10-30 Actuators
Additional Parts For 10-23 Actuators:
Additional Parts For 25 and 30 Actuators:
Quantity Name
1 Pot Kit Subassembly
1 Mounting Bracket
2 Mounting Screw (Bracket)
Quantity Name
1 Pot Kit Subassembly
1 Bracket – Right (Long)
1 Bracket – Left (Short)
2 Spacer (Bracket)
2 Mounting Screw (Bracket/Spacer)
1 Support Bracket – Transformer
1 Spacer – Transformer Support Bracket
(for 23 Size Only)
Quantity Name
1 Circuit Board Subassembly
1 Insulating Board
5 or 6 Washers (Nylon)
5 or 6 Grommets (Rubber)
5 or 6 Mounting Screws (Circuit Board)
1 Nameplate – Circuit Board
1 Nameplate – Base
1 Wiring Label – Cover
1 Instruction Manual
5 Cable Ties
2 Closed End Splice
1 Wire – White
