Standard control features, 1 basic specifications – Flowserve UEX Limitorque User Manual
Page 22
Limitorque UEX FCD LMENIM1205-03-AQ – 05/15
22
6.1 Basic Specifications
The standard UEX controller wiring diagrams are shown in Section 15. Optional wiring diagrams are on
subsequent pages. The most current wiring diagram is provided with the product.
The following control features are included in the basic UEX controller.
For Optional Features, please refer to Section 8-Optional Control Features.
Figure 6.1 – UEX Local Control Panel
6
Standard Control Features
VIEW A-A
Blue
Knob
Red
Knob
Open
(Yes)
Close
(No)
Lights (2)
CSE Control Station
Selector Switch Detail
(Knob removed for clarity)
A
A
