TRVL range Setting end positions
0%=0.0% Select Out of Service.
Set percentage value for desired end posi- tion (e.g. 3%).
Set 0% Select In Service.
Connect calibrator. Move forward to desired end position (0%) and press OK.
100%=100.0% Select Out of Service.
Set percentage value for desired end posi tion (e.g. 97%).
Set 100% Select In Service.
Connect calibrator. Move forward to desired end position (100%) and press OK.
Trvl ctrl Behavior at set end position
Set low Choose between Free (go to mechanical stop), Limit (stop at set end position), and Cut off (go directly to
mechanical stop at set end position).
Set high Similar to Set low.
Values Select position for Cut off and Limit at the respective end positions.
Passcodes Setting passcodes for various functions
Full menu Passcode for access to full menu.
Write prot Passcode for removing write protect.
Expert Passcode for access to Expert menu (TUNING).
Fact set Passcode to return to default values applicable when positioner was delivered.
Numbers between 0000 and 9999 can be used.
Appearance On display
Language Select menu language.
Units Select units.
Def. Display Select value(s) to be displayed during service.
The display reverts to this value 10 minutes after any change is made.
Start menu Start in Basic menu or
Full menu.
Start Logo Shows Flowserve Logo
Orient Orientation of text on display.
Devicedata
HW rev
SW rev General Parameters
Capability
HART Menu with HART parameters. Only amendable
with HART communicator. It is possible to read from display.
The menu contents are shown in the chart on the next page and the various texts are described below:
Close time Minimum time (Min 0.005) from fully open to closed.
Open time Minimum time (Min 0.05) from closed to fully open.
Deadband Setting deadband. Min. 0.2%.
Expert Advanced settings.
Control See explanations below.
Togglestep Test tool for checking functions. Overlays a square wave on the
set value.
Self test Internal test of processor, potentiometer, etc.
TUNING
