10
After installation, ensure all screw connections are tightened correctly and all moving parts are free from excessive
friction.
NOTE!
All products that are covered by an ATEX Certification number ending with an
“X”, special care must be taken when cleaning the surface of the product.
“The enclosure must be cleaned with a damp cloth due to static electricity
for plastic windows/surfaces”
For securing covers and lids, it ’s important to use the correct torque:
Product Size (screw) Torque Nm
I/P cover APEX A9000 M4 0,65 Nm +/- 15%
APEX A9000 M5 1,20 Nm +/- 15%
F5EX and XCL / XML / XV M6 / M8 7 Nm
Covers (thread on) for APEX A9000 EX, D3EX, Tighten fully and secure
Exhaust ports
Apex A9000 exhaust actuator through a hole in the backside,
covered by a plate.
Apex A9000 Explosion proof has 2 x exhaust ports,
located on the flat areas. Make sure that both these
ports are not left open, facing up or side wards.
Protected by a proper bleeder cap or a fitting
with short tube (
≥ Ø 4 mm
inner dia, max 80 mm long) facing downwards Bleeder cap
