PARTS LIST
Models (V)T36ENA, (V)T36ENBA, (V)T36ENRA, (V)T36ENRBA
(V)T36EPA, (V)T36EPBA, (V)T36EPRA, (V)T36EPRBA
PARTS LIST
This list contains replaceable parts used in your fireplace. When
ordering parts, follow the instructions listed under Replacement
Parts on page 34 of this manual.
(V)T36ENA, (V)T36EPA
T36ENBA, T36EPBA
VT36ENBA, VT36EPBA
(V)T36ENRA, (V)T36EPRA T36ENRBA, T36EPRBA VT36ENRBA, VT36EPRBA
DESCRIPTION
QTY.
____
110991-02
110991-01
Rear Refractory Brick Panel
1
____
110990-02
110990-01
Right Refractory Brick Panel
1
____
110989-02
110989-01
Left Refractory Brick Panel
1
PART NUMBER
(V)T36ENA
(V)T36ENRA
(V)T36EPA
(V)T36EPRA
KEY
(V)T36ENBA
(V)T36ENRBA
NO.
(V)T36EPBA
(V)T36EPRBA
DESCRIPTION
QTY.
1
***
***
Firebox Assembly
1
2
***
***
Face Weldment
1
3
108010-01
108010-01
Door Assembly (T Models Only)
1
108010-02
108010-02
Door Assembly (VT Models Only)
1
4
108687-01
108011-01
Top Louver Assembly
1
5
108687-02
108011-02
Bottom Louver Assembly
1
6
108015-01
108015-01
Fireplace Top
1
7
108016-01
108016-01
Fireplace Top Insulation
1
8
***
***
Fireplace Surround
1
9
108074-03
108074-03
Burner Assembly (Natural Gas)
1
108074-04
108074-04
Burner Assembly (Propane/LP Gas)
1
See pages 38 & 39
10
108076-01
108076-01
Burner Base Gasket
1
11
see below
see below
Rear Refractory Brick Panel (B Models Only)
1
12
109082-01
109082-01
Heat Shield
1
13
see below
see below
Right Refractory Brick Panel (B Models Only)
1
14
see below
see below
Left Refractory Brick Panel (B Models Only)
1
15
11418
11418
Push-On Nut
2
16
12105
12105
Screen
2
17
108719-01
108719-01
Screen Rod
1
18
14123
14123
Strain Relief
1
19
21171
21171
Gas Knock-Out Cover
2
20
24353
24353
Handy Box Assembly
1
21
24460
24460
Gas Conduit Assembly
1
22
109006-01
109006-01
Log Set
1
22-1
109007-01
109007-01
Rear Log (Log 1)
1
22-2
110182-01
110182-01
Front Log (Log 2)
1
22-3
109008-01
109008-01
Crossover Log (Log 3)
1
22-4
107347-01
107347-01
Right Log (Log 4)
1
22-5
109009-01
109009-01
Base Log (Log 5)
1
22-6
107348-01
107348-01
Left Log (Log 6)
1
PARTS AVAILABLE - NOT SHOWN
25487
25487
Lava Rock/Bag Assy
1
*** Not a field replaceable part.
