HYDRA NH
4
+ -N Page 21
Timer 1: periodic
Timer2: oneshot↑
Retriggerable N
Resettable N
Trig 2 timer 1
Logic gates All unused
Ion Species Ch1 ion NH4-N
Ch2 ion K+
General No Menu
°C/°F & temp cal 1 Trim °C .0
Unit 200.0 °C
4-20 Trim/Test (not configured)
Millivolt trim (not configured)
4.1.4 Configure and Trim Menu, MASTER/SLAVE
MASTER
Menu Settings
Passwords No Pass Words (not configured)
Default display 0 (not configured)
4-20 assign 4-20 1 : Ch1 PV
4-20 2 : Ch3 PV
Manual Mode Ch1 man mode on: 4-20 1
Initial ch1 manual setting: Bumpless
Ch1 auto entry: timer 3
Ch2 man mode on: 4-20 2
Initial ch2 manual setting: Bumpless
Ch2 auto entry: timer 3
Relay assign/test Relay 1 Ch1 PV
Relay 2 timer 2
Relay 3 timer 1
Relay 4 timer 2
PID Assign PID A & B unused
Clock and timers Clock: Software
Hide Clock N
Hide Rate Y
Hide Flash N
Man trig OK Y
Timer 1: periodic
Timer 2: periodic
Timer 3: oneshot↑
Retriggerable N
Resettable N
Trig 3 AND A
Logic gates AND Gate A
In Timer 1
In Timer/2
