5
English
Installation
●
Exterior view
unit : mm (inch)
Enclosure mounting holes (8 locations)
φ 6.5 (0.26)
481 (18.9) ±1 (0.04)
480 (18.9) ±1 (0.04)
223 (8.8)
434 (17.1) ±0.5 (0.02)
503 (19.8)
516 (20.3) ±1 (0.04)
83 (3.27)
±1 (0.04)
9 (0.35)
±1 (0.04)
18 (0.71) 18 (0.71)
407.9 (16.1)
326 (12.8) ±0.5 (0.02)
95.2 (3.75)
4.9 (0.19)
469 (18.5)
427 (16.8) ±1 (0.04)
27 (1.06) ±1 (0.04)
35 (1.38) 35 (1.38)
35 (1.38)
35 (1.38)
35 (1.38)
13.4
(0.53)
90 (3.54) ±1 (0.04)
90 (3.54) ±1 (0.04)
141 (5.6) ±1 (0.04)
75 (2.95) ±1 (0.04)
436 (17.2) ±2 (0.08)
8-M6
75 (2.95)
M6
19 (0.75)
D-Sub mini 15-pin
connector
DVI-D connector Power connector
RS-232C port
（for FDU2101T only）
