Engine Starting
Now that you have checked the oil, transmission and fuel and are familiar with the controls
you are ready to start the engine. We know you are anxious to drive your DR®
Powerwagon™ 4 x 2 but here are just a few more tips before you are ready.
• Move choke lever to start.
• Depress the clutch pedal (left pedal) and move the gear selector to the neutral-start
position. Note: if the gear selector seems difficult to shift pump the brake.
• Make sure the parking brake is set.
• Move the throttle (on the left side of the handlebar) to S (slow). Note the throttle location
on the left side of the handlebar in Figure 8-B. We have changed the location after the
cover photo was taken.
• Depress the brake pedal (right pedal).
• Turn the key on the start switch and release when the engine starts.
• You can get off the vehicle and move the choke to run.
Figure 8-B
Throttle in Slow
position
