Preparing The DR® POWERWAGON™ 4 x 2 For Operation
We have done our utmost to make it easy to get your DR© POWERWAGON™ 4 x 2 ready
to roll. Please take a few minutes to read through this manual and your engine manual before
attempting operation.
Checking and Adding Oil:
For your convenience the DR® POWERWAGON™ 4 x 2 is shipped fully assembled, with
oil in the engine and transmission. However it is always wise to check the oil levels before
operation. Make sure that the machine is on a level surface and unscrew the oil cap as shown.
Oil should be at the level shown in figure 1. Add oil with the yellow cap off until oil starts to
drip out. You can add oil here or at the oil fill shown in figure 2.
Checking the Transmission Oil:
The transmission is shipped with gear oil but should
be checked before operation. If necessary, add SAE
90W gear oil until it shows 2/3 in the sight glass. See
Figure 3.
Oil Level
Figure 1
Oil fill
Figure 2
Add Trans. oil
Oil sight window
Drain plug
Figure 3
