24 DR ® ROTO-HOG™ Mini Tiller
Parts List - Transmission
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 35994* Mc Lower Transmission Casting Left
2 35985 Seal Shaft 19mm Shaft 32mm Bore
3 35986 Bushing M19 Id X 25.5od D-Profile Flange
4 35987 Worm
5 35988 Spacer Bushing 22 X 11.05 X 2.413mm
6 35989 Bushing M11 Id X 19od D-Profile Flanged
7 35990 Thrust Reducer Bearing M11 X 15od Flange
8 35991 Thrust Washer 28 X 15 X 1.5mm
9 35992 Thrust Bearing 28 X 15 X 2mm
10 35993 Drive Shaft
11 35994 Ball Bearing 9mm X 26mm Double Sealed
12 25737 Clutch Drum Assembly 77.7mm
13 36005* Mc Lower Transmission Casting Right
Ref# Part# Description
14 26121 Dust Cap
15 36006 Bolt M6 X 1.0 X 22 Flange
16 36007 Bolt M6 X 1.0 X 18 Flange
17 26104 Wheel and Drag Mount
18 36008 Bolt M6 X 1.0 X 25
19 36009 Nut M6 X 1.0
20 36010 Nut M8 X 1.25
21 36011 Flat Washer M6 X 13 X 1.75
22 36012 Bolt M6 X 1.0 X 8mm
23 36013 Shim Tine Shaft 35mm X 19mm X
2.2mm
24 26118 Fiber Washer 38 X 19 X 3.2mm
25 36014 Shaft Tine Assembly
26 26119 Transmission Assembly
* Available as Assembly or Kit Only
