DR Power Tow-Behind Vacuum Hose (Pre-August 2010) User Manual
Page 3
CALL
TOLL
FREE
1-800-DR-OWNER iii
Table of Contents
CHAPTER 1............................................................................................................................. 1
INTRODUCING THE DR OPTIONAL ACCESSORIES ................................................... 1
Conventions used in this manual ................................................................................... 1
CHAPTER 2............................................................................................................................. 2
GENERAL SAFETY RULES............................................................................................... 2
CHAPTER 3............................................................................................................................. 3
DR LEAF AND LAWN VACUUM OPTIONAL ACCESSORIES ....................................... 3
Connecting and Using the Optional Hand Vacuum Attachment (Kit No. 18789) ...... 3
Installing and Using the Optional Bagging Accessory................................................... 6
Installing and Using the Optional Mulch-Discharge Attachment (Kit No. 18791)...... 8
Installing the Optional Universal Lawn Deck Adapter ................................................. 10
CHAPTER 4........................................................................................................................... 21
PARTS LISTS AND SCHEMATIC DIAGRAMS.............................................................. 21
Parts List - Hand Vacuum Hose Assembly (Kit No. 18789) ........................................ 21
Schematic Diagram - Hand Vacuum Hose Assembly.................................................. 22
Parts List - Bagging Accessory (Kit # 18796 Commercial, # 18795 Premier Model) . 23
Schematic Diagram - Bagging Accessory ..................................................................... 23
Parts List - Mulch-Discharge Hose (Kit No. 18791).................................................... 24
Schematic Diagram - Mulch-Discharge Hose .............................................................. 24
Parts List - Universal Lawn Deck Adapter (Kit No. 18794) .......................................... 25
Schematic Diagram - Universal Lawn Deck Adapter.................................................... 26
