Hardware Installation
JP1 is used to select the power of the PS/2 keyboard/mouse port.
Selecting 5V_standby will allow you to use the PS/2 keyboard or
PS/2 mouse to wake up the system.
BIOS Setting
Configure the PS/2 keyboard/mouse wake up function in the Inte-
grated Peripherals submenu (“Super IO Device” section) of the BIOS.
Refer to chapter 3 for more information.
Important:
The 5V_standby power source of your power supply must sup-
port
≥720mA.
PS/2 Power Select
1-2 On: 5V
(default)
2-3 On:
5V_standby
X JP1
3 1 2 3 1 2
