Introduction
Processor
Chipset
System Memory
Expansion Slots
Graphics
Audio
Chapter 1 - Introduction
• Socket P 478-pin Micro FCPGA for:
- Embedded Intel
® Core TM 2 / Celeron ® M processor
• 1066/800/667MHz FSB
• Intel
® 45nm transistor technology
• Intel ® Trusted Execution Technology (Intel ® TXT)
• Intel ® Virtualization Technology (Intel ® VT) DMA
• Supports Data Bus Inversion (DBI)
• Supports Message Signaled Interrupt (MSI)
• Supports Intel
® architecture with Intel ® Wide Dynamic Execu-
tion
• Intel ® chipset
- Intel ® GM45 Express chipset
- Intel ® ICH9M I/O Controller Hub
• Two 204-pin SODIMM sockets
• Supports DDR3 800/1066MHz
• Supports up to 8GB system memory
• 64-bit wide per channel
• 256Mb, 512Mb, 1Gb and 2Gb memory technologies
• Supports non-ECC x8 and x16 DIMMs
• Supports DDR3 On-Die Termination (ODT)
• Supports partial writes to memory using data mask signals
(DM)
• Supports 1 PCI Express x16
• Supports up to 4 PCI Express x1 (PCIE 1.1)
• Supports up to 4 PCI (PCI 2.3)
• Internal graphics features
- Intel GMA 4500 integrated graphics engine
- 533MHz core render clock
- Supports 3D, 2D and video capabilities, DX10 and OpenGL
2.1
• Integrated graphics interface
- Analog CRT
- Integrated 300MHz
- Analog monitor supports up to QXGA
- LVDS interface
- Panel support up to UXGA (1600x1200)
- 25MHz-112MHz single/dual channel up to 2x24bpp panel
support
• Supports AC97 on Azalia interface (depends on the CODEC
used on the carrier board)
Specifications
