BIOS Setup
North Bridge
Low MMIO resources
align at 64MB/1024MB
BIOS SETUP UTILITY
Version 2.00.1201. Copyright (C) 2009 American Megatrends, Inc.
Memory Information
CPU Type
Total Memory
Memory Slot 1
CAS# Latency (tCL)
RAS# Active Time (tRAS)
Row Precharge Time (tRP)
RAS# to CAS# Delay (tRCD)
Write Recovery Time (tWR)
Row Refresh Cycle Time (tRFC)
Write to Read Delay (tWTR)
Active to Active Delay (tRRD)
Read CAS# Precharge (tRTP)
Low MMIO Align
Initiate Graphic Adapter
VT-d
PCI Express Port
IGD Memory
PAVP Mode
Display Present
Arrandale
2048 MB (DDR3 1066)
2048 MB (DDR3 1066)
7
20
7
7
8
60
4
4
5
[64M]
[PEG/IGD]
[Disabled]
[Auto]
[64M]
[Disabled]
[PCIex16]
Low MMIO Align
Selects the low MMIO resources align at 64MB or 1024MB.
Initiate Graphic Adapter
Selects the graphics controller to use as the primary boot device.
When this field is set to “IGD Function”, you can use the display output from
both the integrated graphics and PCIe x16 graphics card to support total of 4
multiple displays (Extended Mode).
VT-d
The options are Enabled and Disabled.
PCI Express Port
These field is used to enable or disable the PCI Express port function.
Chipset
→ ←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save ESC: Exit
