DFI CP908-B User Manual
Page 31
31
2
Hardware Installation
5. The photo below shows the component side of the board with the bolts al-
ready fixed in place.
6. Grasping CP908-B by its edges, position it on top of the carrier board with its
mounting holes aligned with the bolts on the carrier board. This will also align
the COM Express connectors of the two boards to each other.
Bolts
COM Express connectors
on CP908-B
COM Express connectors
on the carrier board
