Hardware Installation
1 GNDB1 56 NC
2 GBE0_ACT# 57 GPO2
3 LPC_FRAME# 58 PCIE_RX3+
4 LPC_AD0 59 PCIE_RX3-
5 LPC_AD1 60 GNDB7
6 LPC_AD2 61 PCIE_RX2+
7 LPC_AD3 62 PCIE_RX2-
8 LPC_DRQ0# 63 GPO3
9 LPC_DRQ1# 64 PCIE_RX1+
10 LPC_CLK 65 PCIE_RX1-
11 GNDB2 66 WAKE0#
12 PWRBTN# 67 WAKE1#
13 SMB_CK 68 PCIE_RX0+
14 SMB_DAT 69 PCIE_RX0-
15 SMB_ALERT# 70 GNDB8
16 SATA1_TX+ 71 LVDS_B0+
17 SATA1_TX- 72 LVDS_B0-
18 SUS_STAT# 73 LVDS_B1+
19 SATA1_RX+ 74 LVDS_B1-
20 SATA1_RX- 75 LVDS_B2+
21 GNDB3 76 LVDS_B2-
22 SATA3_TX+ 77 LVDS_B3+
23 SATA3_TX- 78 LVDS_B3-
24 PWR_OK 79 LVDS_BKLT_EN
25 SATA3_RX+ 80 GNDB9
26 SATA3_RX- 81 LVDS_B_CK+
27 WDT 82 LVDS_B_CK-
28 AC_SDIN2 83 LVDS_BKLT_CTRL
29 AC_SDIN1 84 VCC_5V_SBYB1
30 AC_SDIN0 85 VCC_5V_SBYB2
31 GNDB4 86 VCC_5V_SBYB3
32 SPKR 87 VCC_5V_SBYB4
33 I2C_CK 88 NC
34 I2C_DAT 89 VGA_RED
35 THRM# 90 GNDB10
36 USB7- 91 VGA_GREEN
37 USB7+ 92 VGA_BLUE
38 USB45_OC# 93 VGA_HSYNC
39 USB5- 94 VGA_VSYNC
40 USB5+ 95 VGA_I2C_CK
41 GNDB5 96 VGA_I2C_DAT
42 USB3- 97 TV_DAC_A
43 USB3+ 98 TV_DAC_B
44 USB01_OC# 99 TV_DAC_C
45 USB1- 100 GNDB11
46 USB1+ 101 VCC_12VB1
47 EXCD1_PERST# 102 VCC_12VB2
48 EXCD1_CPPE# 103 VCC_12VB3
49 SYS_RESET# 104 VCC_12VB4
50 CB_RESET# 105 VCC_12VB5
51 GNDB6 106 VCC_12VB6
52 NC 107 VCC_12VB7
53 NC 108 VCC_12VB8
54 GPO1 109 VCC_12VB9
55 NC 110 GNDB12
Row B
