BIOS Setup
Enable or Disable Serial
Port (COM)
BIOS SETUP UTILITY
Version 2.00.1201. Copyright (C) 2009 American Megatrends, Inc.
Serial Port 1 Configuration
Serial Port
Device Settings
Change Settings
Device Mode
Advanced
[Enabled]
IO=3F8h; IRQ=4;
[Auto]
[Serial Port Func...]
Serial Port 1 Configuration to Serial Port 4 Configuration
→ ←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save ESC: Exit
UART Configuration
This section is used to configure the serial port functions.
Set Parameters of Serial
Port 1 (COMA)
BIOS SETUP UTILITY
Version 2.00.1201. Copyright (C) 2009 American Megatrends, Inc.
UART Configuration
Super IO Chip

Serial Port 1 Configuration

Serial Port 2 Configuration

Serial Port 3 Configuration

Serial Port 4 Configuration
Advanced
Fintek F81216
→ ←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save ESC: Exit
Serial Port
Enables or disables the serial port.
Change Settings
Selects the IO/IRQ setting of the I/O device.
