D-Link DES-1228P User Manual
Page 24
2
2
0
0
Link/Act
On
When the respective combo port is connected to a
network, the Link/Act LED light is on.
Blinking When the LED is blinking, the respective combo port is
transmitting or receiving data on a network.
Off No
link.
1000Mbps
On
When the 1000Mbps LED light’s on, the respective port
is connected to a 1000Mbps Gigabit Ethernet network.
Off
When the respective port is connected to a 100Mbps Fast
Ethernet or no link.
100Mbps
On
When the 100Mbps LED lights on, the respective port is
connected to a 100Mbps Fast Ethernet network.
Off
When the respective port is connected to a 1000Mbps
Gigabit Ethernet network or no link.
Ports 27~28 10/100/1000 Base-T LEDs
Link/Act
On
When the Link/Act LED light is on, the respective port is
successfully connected to an Ethernet network.
